A bit of a disaster

I like to post the good and the bad so here goes. M92 was the goal here but the data is very poor. I think that I have accumulated frost on the CCD sensor that has corrupted the entire data set. 45 x 60 subs through each RGB filter was just impossible to calibrate. I assumed firstly that it was a setting in Pixinsight that I was unfamiliar with, quite possible considering it is so new to me but after a new set of flats, dark flats and calibrated in both DSS & Pixinsight the results were just the same. I will take the data to Breckland Observatory this week and let a few of our resident Pixinsight experts have a play too. Here is the data anyway. Full size image and crop.#notimpressed. However I was happy with the focus. Win win.

M94

My second capture and full process with Pixinsight is a spectacular galaxy with a double shell. M94 is a bit of a cosmic mystery. Studies suggest very little to no dark matter. Possible suggestions of a galactic collision also seem to be dispelled so overall a bit of a mystery.

M94 has an inner ring with a diameter of 70". Given its distance, about 5,400 light-years (1,700 pc)) and an outer ring with a diameter of 600″ (about 45,000 light-years (14,000 pc)). These rings appear to form at resonance points in the disk of the galaxy. The inner ring is the site of strong star formation activity and is sometimes referred to as a starburst ring. This star formation is fueled by gas driven dynamically into the ring by the inner oval-shaped bar-like structure. Considering my image scale is jus under 2 arc seconds per pixel, the structure in the spiral arms is seriously impressive.

I must admit also I am seriously impressed by the quality of the last 2 posts that have been fully processed in Pixinsight.

M51 The Whirlpool Galaxy

The usual Malcolm luck happened last month, I closed down the observatory for some maintenance and what do we get a week full of clear skies. Still it gave me chance to get some  jobs complete such as wiring the dome to the wireless controller. Disappointing that the weather was clear but since rebuild, a PA and test of tracking and guiding was needed,  Every set up nicely and as expected and  from there I have managed over 4 nights captured five and a half hours of LRGB data on target.

Guiding has been excellent with excellent with numbers as low as .30 arc seconds accuracy. I will be happy if these numbers continue. As you can see target was M51, always a favourite and captured many times previously.

     I am always astounded and I love the ZWO Asiair pro for its simplicity in doing almost everything now. Some  lovely new additions to the software update now include now sky atlas and the ability to name filters. There are of course many things that it cannot do including composing mosaics but I can live with it for now simply because there are other pieces of software such as Telescopius that communicates perfectly with the ability to download a CSV file with the mosaic parameters. There are several summer projects that will use this feature so look out for my updates on this feature.

So the target was M51 using the LRGB filters with an aim for a couple of hours on each filter. In case of bad weather I set the imaging run to 30 minutes a filter. At least I would have something to process if the project fell flat. I have also the zwo electronic focusser so the whole process is totally automated when switching from filter to filter to imaging again takes under two minutes.

A Typical stretched 180 second sub frame (right) A small target for 550mm of focal length but I am hopeful for a decent crop out of the final data stack.

So after three good nights I have managed five and half hours of data with 30x 3 minutes sub frames on RGB and 1 hour of Luminance data.

During bad nights I also took the opportunity and captured a complete set of calibration frames too from darks, dark flats, & Flats.

To top it all I have finally taken the plunge into the technical world of Pixinsight. A scary thought but with the help of some serious video instruction from Adam Block I have created my first image.

Prior to starting the image processing I used Image calibration & Image combination to create all my master calibration frames.

Again this is all very new to me and I followed this process to create my first image.

Calibrated and stacked using the new WBPP (weighted batch pre processing) script new and updated script that works every bit as good as six or seven steps of manual image registration.

Part of this hobby also includes trawling the expanse of YouTube and looking for videos that suit you knowledge set and by chance I found a chap called Richard Bloch. and found Basic image processing in Pixinsight 1.8, the cover image was of M51 and I was processing M51 so thought it worth a look, Turns out his explanations and information were spot on. I will send him a message to say hello and thank you

Dynamic Crop

Autoomatic background extractor

Colour Calibration

Histogram transformation

TGV Noise

Range select

Unsharp mask

curves.

Final result I am more than pleased with.
